- Name：
698/2700MHz 3DBI magnetic antenna
- Model No.：
G15366B
- Frequency Range ：
698-960/1710-2700MHz
- Gain：
3DBI
- Cable Length：
3M RG174 Black
- Connector：
SMA male
|
Electrical Specifications |
|
|
Model No. |
G15366B |
|
Frequency Range |
698-960/1710-2700MHz |
|
Gain |
3dBi |
|
VSWR |
≤2.5 |
|
Input Impedance |
50Ω |
|
Polarization |
Vertical |
|
Horizontal Half Power Angle |
360° |
|
Vertical Half Power Angle |
70° |
|
Max Input Power |
50W |
|
Lightning Protection |
DC Ground |
|
Mechanical Specifications |
|
|
Working Temperature |
-40℃~﹢65℃ |
|
Connector Type |
SMA male |
|
Cable Type |
RG174 Black |
|
Cable Length |
3m |
|
Antenna Weight |
38g |
|
Size |
Φ30x(228±5)mm |
|
Mounting |
Magnetic Base |
|
Color |
Black |
698/2700MHz 3DBI magnetic antenna
